Switch Setting Table (*: default setup)
CPU Frequency
S1.1
*100 OFF
66 ON
CPU Pipelined
S1.8
*Enabled OFF
Disabled ON
M-System Disk On Chip
S2.1
Disabled OFF
C0000 ON
C8000 ON
D0000 ON
*D8000 ON
BIOS Fresh
S2.4
*Enabled ON
Disabled OFF
RTC Clear
S2.5
Enabled ON
*Disabled OFF
Switches and Connectors
S1.2 S1.3 S1.4
OFF ON OFF
ON ON OFF
S2.2 S2.3
X X
ON ON
ON OFF
OFF ON
OFF OFF
S1.5 S1.6 S1.7
OFF OFF OFF
OFF ON OFF
