Feature
PXE Lanboot
Boot Up Num lock Statu
Gate A20 Option
Typematic Rate Setting
Typematic Rate
Typematic Delay
PS/2 Mouse Function
Video BIOS Shadow
C800 – CBFF Shadow
CC00 – CFFF Shadow
D000 – D3FF Shadow
D400 – D7FF S hadow
D800 – DBFF Shadow
DC00 – DFFF Shadow
Shadow Read/Write
Memory Hole at 15M-16M
Kontron User's Guide MOPSlcdLX
Option
Disabled Enables or disables the PXE Lanboot option
Enabled
s Off On or Off tur
board feature)
On
Normal Normal = a pin in the keyboard controller checks
GateA20
Fast
Fast = lets chipset controls GateA20
Disabled Enables or disables manual adjustability
Enabled
6, 8, 10, 12, 15,20, Sets number of times to repeat a keystroke per se-
cond if you hold the key down
24, 30 chars/sec.
250, 500, 750, 1000 Sets delay time after key is held down before it be-
gins to repeat the keystroke
ms
Disabled Disabled prevents installed PS/2 mouse from func-
tioning but frees IRQ12
Enabled
Enabled forces the PS/2 mouse port to be enabled
regardless if a mouse is present
Disabled Controls shadowing of Video BIOS area
Enabled
Disabled Accesses to this upper m
bus if Disabled or to loca
Enabled
Disabled See above
Enabled
Disabled
See above
Enabled
Disabled See above
Enabled
Disabled See above
Enabled
Disabled See above
Enabled
Disabled Normally s
on to enable Write operation
Enabled
Disabled Enables or disables the memory hole at 15MB for
ISA bus access
Enabled
