I/O Monitor CAN Node
Screw head
mounting slot (2x)
(Head's diameter >5 mm
and <8 mm)
I/O Monitor
Fan Control Inputs & Outputs
Terminal Block X***
The I/O Monitor CAN Bus Node
enables you to decentralize and
increase the
monitoring and output controlling
signals in your Smartpack based DC
power supply system. Also, it
monitors and
compartment temperature inside fan-
cooled outdoor cabinets.
Read also the "Installation Guide
I/O Monitor CAN Node", document
351503.033.
I/O ID DIP Switch Position
⎯
Monitor #
1 2
st
1 Monitor 81
OFF⎯OFF⎯OFF⎯OFF
nd
2 Monitor 82 ON ⎯OFF⎯OFF⎯OFF
rd
3 Monitor 83
OFF⎯ ON⎯OFF⎯OFF
th
4 Monitor 84 ON ⎯ ON⎯OFF⎯OFF
th
5 Monitor 85 OFF⎯OFF⎯ON ⎯OFF
ON ⎯OFF⎯ ON⎯OFF
6th Monitor 86
th
7 Monitor 87 OFF⎯ON⎯ ON ⎯OFF
th
8 Monitor 88 ON ⎯ ON⎯ ON⎯OFF
th
9 Monitor 89
OFF⎯OFF⎯OFF⎯ON
th
10 Monitor 90 ON ⎯OFF⎯OFF⎯ON
th
11 Monitor 91 OFF⎯ON ⎯OFF⎯ON
th ON ⎯ON ⎯OFF⎯ON
12 Monitor 92
th
13 Monitor 93 OFF⎯OFF⎯ON ⎯ON
th
14 Monitor 94 ON ⎯OFF⎯ ON ⎯ON
26
DIN Rail
mounting
clips
Pin 1
number of input
controls the
I/O Monitor
DIP switch configuration
ID <81>
⎯ ⎯
(All switches OFF)
3 4
Note:
• DIP switch
positions 5
through 8 are
always to be OFF
• The monitor's
ID # corresponds
to the DIP
switch's binary
value plus 81

DIP switches

CAN ID address
DIP switch #1
CAN port 1&2
Electrically identical
I/O Monitor

Configurable Inputs

Terminal Block X*
Voltage free relay outputs and Configurable monitoring inputs
I/O Monitor
CAN
port 1&2
RJ45, 8 pins
DIP
Switches
1
2
3
4
(5-8 always
OFF)
Out
Quick Start Guide Minipack PS System
CAN Bus Nodes
Alarm
LED Lamp (red)
Warning
LED Lamp (yellow)
Power
LED Lamp (green)
Input 6
I/O Monitor Connections
FUNCTION SIGNAL PIN-OUT
X:*
–
Config. Input
1
+
–
Config. Input 2
+
–
Config. Input
3
+
–
Config. Input 4
+
–
Config. Input 5
+
–
Config. Input 6
+
X:**
NO
Relay 1
C
NC
NO
Relay 2
C
NC
NO
Relay 3
C
NC
NO
Relay 4
C
NC
NO
Relay 5
C
NC
NO
Relay 6
C
NC
–
Not in use
+
X:***
1
+
Temperature Sense 1
−
2
3
+
Temperature Sense 2
−
4
5
Tachometer Input 1
Tachometer Input 2
6
7
Speed Control Output 1
8
Speed Control Output 2
(Customer Connections)
In
356808.103, 1v2-2008-10

Relay Outputs

Terminal Block X**
Relay 1
Input Circuit 1
Input Circuit 2
Input Circuit 3
Input Circuit 4
Input Circuit 5
Input Circuit 6
Alarm Circuit 1
Alarm Circuit 2
Alarm Circuit 3
Alarm Circuit 4
Alarm Circuit 5
Alarm Circuit 6
(To be shorted)
Temperature
Sensor 1
Temperature
Sensor 2
Fan Speed Monitor 1
Fan Speed Monitor 2
Fan Speed Control 1
Fan Speed Control 2
2
1.5 mm , max.
wire section
