CAN Bus Nodes
Load Monitor CAN Node
The Load Monitor CAN Bus Node enables you to decentralize and increase the number of input
fuse monitoring and current sense signals in your Smartpack based DC power supply system. The
fuse monitoring inputs are suitable for monitoring a wide range of breakers in both positive and
negative DC distributions.
DIP switches
CAN ID address
DIP switch #1
CAN port 1&2
Electrically identical
Load Monitor
Fuse Monitoring Inputs
Read also the "Installation Guide
Load Monitor CAN Node",
document 351506.033.
Load ID DIP Switch Position
⎯
Monitor #
1 2
st
1 Monitor 49
OFF⎯OFF⎯OFF⎯OFF
nd
ON ⎯OFF⎯OFF⎯OFF
2 Monitor 50
rd
3 Monitor 51
OFF⎯ ON⎯OFF⎯OFF
th
4 Monitor 52 ON ⎯ ON⎯OFF⎯OFF
th
OFF⎯OFF⎯ON ⎯OFF
5 Monitor 53
ON ⎯OFF⎯ ON⎯OFF
6th Monitor 54
th
7 Monitor 55 OFF⎯ON⎯ ON ⎯OFF
th
8 Monitor 56 ON ⎯ ON⎯ ON⎯OFF
th
9 Monitor 57
OFF⎯OFF⎯OFF⎯ON
th ON ⎯OFF⎯OFF⎯ON
10 Monitor 58
th
11 Monitor 59 OFF⎯ON ⎯OFF⎯ON
th
ON ⎯ON ⎯OFF⎯ON
12 Monitor 60
th
OFF⎯OFF⎯ON ⎯ON
13 Monitor 61
th
14 Monitor 62 ON ⎯OFF⎯ ON ⎯ON
Quick Start Guide Minipack PS System
Alarm
LED Lamp (red)
Warning
LED Lamp (yellow)
Power
LED Lamp (green)
Input 1
Terminal Block X*
Load Monitor
DIP switch configuration
ID <49>
⎯ ⎯ (All switches OFF)
3 4
Note:
• DIP switch
positions 5
through 8 are
always to be OFF
• The monitor's
ID # corresponds
to the DIP
switch's binary
value plus 49
mounting slot (2x)
(Head's diameter >5 mm
Load Monitor
Current Sense Inputs
Terminal Block X**
Input 1
Voltage free relay outputs and Configurable monitoring inputs
Load Monitor
CAN
port 1&2
RJ45, 8 pins
DIP
Switches
1
2
3
4
(5-8 always
OFF)
356808.103, 1v2-2008-10
Appendix
Screw head
and <8 mm)
Load Monitor Connections
FUNCTION SIGNAL PIN-OUT
X:*
–
Config. Input
1
+
–
Config. Input 2
+
–
Config. Input
3
+
–
Config. Input 4
+
–
Config. Input 5
+
–
Config. Input 6
+
–
Config. Input 7
+
–
Config. Input 8
+
X:**
–
Sense Input
1
+
–
Sense Input 2
+
–
Sense Input
3
+
–
Sense Input 4
+
–
Sense Input 5
+
–
Sense Input
6
+
–
Sense Input 7
+
–
Sense Input 8
+
1.5 mm
(Customer Connections)
DIN Rail
mounting
clips
Input Circuit 1
Input Circuit 2
Input Circuit 3
Input Circuit 4
Input Circuit 5
Input Circuit 6
Input Circuit 7
Input Circuit 8
Input Circuit 1
Input Circuit 2
Input Circuit 3
Input Circuit 4
Input Circuit 5
Input Circuit 6
Input Circuit 7
Input Circuit 8
2
, max.
wire section
25
