Appendix
Battery Interface Card ~ Terminals & Pin-out
The Smartpack controller's battery monitoring signals are accessible on D-Sub connectors CON4
and CON3, on the controller's rear panel.
Using the Battery Connection Kit ⎯ which consists of a Battery Interface Card (Art. 200576) and
a standard 15 pins D-Sub cable ⎯ you can make the signals on CON4 accessible at any suitable
location inside your system, e.g. near the battery blocks.
When extra battery monitoring signals are required, you can use an extra Battery Connection Kit
connected to the controller's CON3.
For detailed information about the card's pin-out location and terminal block connections, see the
figures in this section.
Battery Connection Kit
15 pins D-Sub cable
Card Art.200576
Temperature Sense Kit
Temp. Sensor cable
Temp. sensor
For temperature monitoring of the battery
compartment, we recommend the use of the
Temperature
connecting the sensor cable directly to the
terminals, pin 9-10.
The Temperature Sense Kit is connected to
the Battery Interface Card (Art. 200576), or
directly to the controller's CON3 or CON4,
if unused.
Terminals & Pin-out Location
CON3
Smartpack
PCB 200576
PCB 200576
CON3A or CON4A
X3/X4
1
14
Battery Interface Card, Art. 200576
20
Cable
Lugs
Sense Kit, instead
CON2
CON1
CON4
CON5
For Temp. Sense Kit
X**/X*
Serial Switch
1
Battery Connections (Internal)
Configurable monitoring digital inputs
FUNCTION
Card Art.200576
In
Batt. Symmetry 1 + −
Batt. Symmetry 2
Batt. Symmetry 3
Batt. Symmetry 4
Temperature Sense 1
1 11
5 15
CON3A or
CON4A
15-pins
D-Sub female
1 5
11 15
of
(Alternative use of Temp. Sense Kit,
instead of connecting to X4: 9-10)
Battery Connections (Internal)
Configurable monitoring digital inputs
FUNCTION
Card Art.200576
In
Batt. Symmetry 5
Batt. Symmetry 6
Batt. Symmetry 7
Batt. Symmetry 8
Temperature Sense 2
1 11
5 15
CON3A or
CON4A
15-pins
D-Sub female
1 5
11 15
(Alternative use of Temp. Sense Kit,
instead of connecting to X3: 9-10)
The Temperature Sense Kits may also be connected directly to the
Smartpack controller's CON3 or CON4, if these connectors are unused.
Quick Start Guide Minipack PS System
Battery Monitoring
SIGNAL PIN-OUT
X4
1
2
3
+
−
4
5
+
−
6
+
7
−
8
9
+
−
10
11
(NA)
12
13
(NA)
14
(Internal Connections)
2
1.5 mm , max.
wire section
X**/X*
15-pins D-Sub male
15-pins
D-Sub female
Temperature Sense 1
SIGNAL PIN-OUT
X3
1
+
−
2
3
+
−
4
5
+
−
6
+ 7
−
8
9
+
−
10
11
Batt Current 2
12
13
Batt Fuse Fail 2
14
(Internal Connections)
2
1.5 mm , max.
wire section
X**/X*
15-pins D-Sub male
15-pins
D-Sub female
Temperature Sense 2
356808.103, 1v2-2008-10
