Alarms & Monitoring
Standard Alarm Relays & Digital Inputs
Standard Relays & Digital Inputs
NO
Normal Mode
Com
Relay X
(Energized coil)
NC
NO
Alarm Mode
Com
Relay X
(De-energized coil) NC
Minipack PS System
Correct Use of Alarm Outputs (example)
+
Digital Input X
(Normal mode)
—
+
Digital Input X
(Activated)
—
Minipack PS System
Correct Use of Digital Inputs (example)
Alarm Interface Card ~ Terminals & Pin-out
The Smartpack controller's alarm and digital input monitoring signals are accessible from the
controller's rear panel, on mini power connector CON1 (2 outputs & 2 inputs).
Using the Alarm Interface Card (Art. 218470) plugged to Smartpack's CON1, you can make the
signals on CON1 accessible on terminal block X1.
For detailed information about the card's pin-out location and terminal block connections, see the
figures in this section.
Terminals & Pin-out Location
CON2
Card neck for Smartpack
cable fastening
Card 218470
Alarm Outputs & Digital Inputs Card
Art. 218470
Quick Start Guide Minipack PS System
The alarm outputs in Minipack systems use the Fail-Safe
Operation Mode (relay coils energized in the system's
+
normal operation mode). When the system is in alarm mode,
the alarm relay coils are de-energized.
—
+
The figure shows the position of the relay contacts when the
—
relay coils are de-energized (PS system in alarm mode)
Normal Mode
External Relay Y
In order to implement monitored fail-safe digital inputs
(Energized coil)
circuits, the external relay coil must be energized and the
Alarm Mode
External Relay Y
contacts closed in the system's normal mode of operation.
(De-energized coil)
CON3
CAN1
10
CON4
X1
CON5
CON1
1
Alarm Outputs & Digital Inputs
Voltage free relay outputs and Configurable monitoring digital inputs
FUNCTION
Card Art.218470
To CON1
In
1
Digital Input 1
X1
Digital Input 2
10
Common Alarm
Mains Alarm
(Customer Connections)
The figure shows the position of the relay contacts when the PS
system is in alarm mode of operation; the relay coils are then de-
energized (fail-safe mode). The relay outputs are preprogrammed
from factory (Factory Settings).
356808.103, 1v2-2008-10
Appendix
Connections
SIGNAL PIN-OUT
X:1
Out
1 Input Circuit 1
+
−
2
Input Circuit 2
3
+
−
4
5
NO
Relay 1
COM 6
Alarm Circuit 1
NC 7
8
NO
Relay 2
9
Alarm Circuit 2
COM
10
NC
2
1.5 mm , max.
wire section
