Appendix
CAN Bus Nodes
The CAN Bus Nodes are control units connected to the power system's CAN bus. They have a
rugged sealed-plastic design, with DIN-rail or Velcro tabs as standard mounting options.
When the CAN bus address is configured and the unit connected to the bus, it will automatically
communicate with the Smartpack controller ("plug and play"). Configure then the CAN node
functionality using PowerSuite.
Battery Monitor CAN Node
The Battery Monitor CAN Bus Node enables you to decentralize and increase the number of battery
symmetry measurements in your Smartpack based DC power supply system. Also, it monitors the
battery compartment temperature – using the built-in sensor – the battery fuse – with a fuse
monitoring input – and the battery current – via a current sense input.
Battery Monitor
DIP switch #1
Battery ID DIP Switch Position
⎯
Monitor #
1 2
st
1 Monitor 33
OFF⎯OFF⎯OFF⎯OFF
nd
ON ⎯OFF⎯OFF⎯OFF
2 Monitor 34
rd
3 Monitor 35
OFF⎯ ON⎯OFF⎯OFF
th
ON ⎯ ON⎯OFF⎯OFF
4 Monitor 36
th
OFF⎯OFF⎯ON ⎯OFF
5 Monitor 37
ON ⎯OFF⎯ ON⎯OFF
6th Monitor 38
th
OFF⎯ON⎯ ON ⎯OFF
7 Monitor 39
th
ON ⎯ ON⎯ ON⎯OFF
8 Monitor 40
th
9 Monitor 41
OFF⎯OFF⎯OFF⎯ON
th
ON ⎯OFF⎯OFF⎯ON
10 Monitor 42
th
OFF⎯ON ⎯OFF⎯ON
11 Monitor 43
th
ON ⎯ON ⎯OFF⎯ON
12 Monitor 44
th
OFF⎯OFF⎯ON ⎯ON
13 Monitor 45
th
ON ⎯OFF⎯ ON ⎯ON
14 Monitor 46
Read also the "Installation Guide Battery Monitor CAN Node", document 351507.033.
24
CAN port 1&2
Electrically identical
DIP switches
CAN ID address
Battery Monitor
DIP switch configuration
ID <33>
(All switches OFF)
⎯ ⎯
3 4
Note:
• The
monitor's
ID #
corresponds
to the DIP
switch's
binary value
plus 33
Or
RJ45 CAN bus
termination plug,
if the Battery
Monitor is the
last node in the
CAN bus
Quick Start Guide Minipack PS System
LED Lamp (red)
Pin 8
Pin 1
Monitor Inputs
Terminal Block
Battery Monitor Connections
Battery
Monitor
CAN port 1&2
RJ45, 8 pins
CAN Bus Nodes
Warning
Alarm
LED Lamp (yellow)
Power
LED Lamp (green)
Battery Monitor
Part 242100.300
FUNCTION SIGNAL PIN-OUT
X:*
+
Batt. Symmetry 1
Batt. Symmetry 2 +
Batt. Symmetry 3 +
Batt. Symmetry 4 +
+
Batt. Fuse
−
+
Batt. Current
−
2
1.5 mm , max.
wire section
Built-in Battery
Temperature Sensor
