- Page 1 RECTIFIER PSR06-W USER MANUAL UM_PSR06-W_E_R1.1 Notes to this manual...
- Page 2 Supplier: Eltek Valere Deutschland GmbH Industrial Division Schillerstraße 16 D-32052 Herford + 49 (0) 5221 1708-210 + 49 (0) 5221 1708-222 Email Info.industrial@eltekvalere.com Internet http://www.eltekvalere.com © Copyright ELTEK VALERE DEUTSCHLAND GmbH 2009. All rights reserved. ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1...
- Page 3 2009-04-16 Revision Description of change Writer Date Reworked edition on base of the further manual “BHB-PSR06-W.D25- 2008-02-14 1000.HB101”: Layout changed, several minor text corrections New revision status numbering (X.X) introduced, values for input 2009-04-08 voltage range changed (>>wide input range).
-
Page 4: Table Of Contents
Connection Table of Input and Output Terminals....................15 MAINTENANCE..................................16 FAULT FINDING INSTRUCTIONS............................17 9.1. Output voltage failure ............................17 9.2. Output voltage deviation ............................17 TECHNICAL DATA................................18 10.1. General Technical Data............................18 10.2. Type Specific Data..............................20 DIMENSIONAL DRAWINGS/FRONT VIEW ........................21 NOTES....................................22 ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... -
Page 5: Safety Instructions And Waste Disposal Rules
The above statement from EU directive 2002/96/EC applies to all electric devices installed within EU countries. In countries outside the EU, different rules may apply regarding waste disposal of electric devices. For more information about waste disposal of your discarded equipment, contact your ELTEK VALERE DEUTSCHLAND partner. ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... -
Page 6: General Information
Page 6 (24) General Information The primary switched mode rectifier type PSR06-W (named SMPS on the next pages) delivers an output power of approx. 600W. Typical applications are DC power supplies and uninterruptable power supply with battery. Rectifiers of type SMPS have good dynamic regulation properties concerning input voltage changes and load varia- tions. -
Page 7: Start Up Procedure
The losses per module are approx. 40 to 80W (depends on type). Operation All operation elements are located on the front panel of the module. The function of each element is explained on the following pages. See also the front panel drawing on section 7.1. ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... -
Page 8: Functions
Rectifier PSR06-W User Manual Page 8 (24) Functions 5.1 Circuit diagram FIG. 1: Block Diagram PSR06-W ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... -
Page 9: Electrical Function Description
EN 60950 and VDE 0160. 5.2.2 Input A one-pole mains switch is used to switch on and off the unit. The unit is switched on by a run-up stage which limits the switch-on current to <I ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... -
Page 10: Output
This signal is included in the collective failure signal of the rectifier. Additional there is an optocoupler signal (V O.K.) At operation with internal decoupling diodes the voltage before diodes will be measured. ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... -
Page 11: Output Voltage Low
V/5mA. The opto couplers switches off at error. The collective failure signal is delayed for approx. 1sec. The relay contacts between Pin 3 and Pin 5 of X2 are open and between Pin 4 and Pin 5 are closed at error. ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... -
Page 12: Output And Threshold Adjustment
The monitoring thresholds automatically follow the adjusted nominal values of output voltage. The monitoring thresholds for mains/step-up-converter and over heating are not changeable. Details about the adjustment ranges of several threshold values, see section “Technical Data”. ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... -
Page 13: External Functions
The rectifier module has a second charge line (boost charge line). To select this mode connect a voltage to pin 1 of output connector X3 (see cap. 7.3). The voltage value can be adjusted by the user. ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... -
Page 14: Operation Elements And Connectors
Class 1 with reference to the nominal output value of the unit. The indication instrument can be converted to the indication of the adjusted theoretical value for the regulation and monitoring via an external circuit of the signal plug. ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... -
Page 15: Connection Table Of Input And Output Terminals
Terminal X3: X3/Pin Function Control input 2. charging– characteristic/Discharge test (+) External On/Off Optocoupler common emitter Optocoupler C ” U present” +15V DC Optocoupler C "I " Temperature sensor lead (+) Compensating connection for current distribution ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... -
Page 16: Maintenance
Deposits of dust can result in reduced cooling and could also result in conductive impurities in combi- nation with dew formation or high moisture. ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... -
Page 17: Fault Finding Instructions
>>Corrective action: Correct the potential drop by increasing the output voltage of the unit! If the unit still does not work even though all checks have been done, contact your sales agent or the ELTEK VALERE INDUSTRIAL service department. ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... -
Page 18: Technical Data
≥97% of the adjusted output voltage floating ≥85% of the adjusted output voltage without current limit or U Monitoring output under- voltage „U<„ green LED „Vout>Vmin“, with potential-free contact Monitoring output over- voltage „U>„ red LED “Vout>” ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... - Page 19 VDE 0160 issue 5.88 Pt. 7.2.2 Finish RAL 7035 (front plate) Weight approx. 5.3kg Dimensions 280 x 285 x 95mm (H x W x D) Connection terminals: AC-Input, DC-Output Terminal X1 Signalling Terminal X2/X3 Protective conductor connection Bolt M4/Terminal X1 ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1...
-
Page 20: Type Specific Data
Adjustment range 38.4 bis 48V 48 bis 60V 86.4 bis 108V 19.2 to 24V DC over voltage V> Threshold value 135V Adjustment range 52 to 60V 66 to 75V 119 to 135V 26 to 30V ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... -
Page 21: Dimensional Drawings/Front View
Rectifier PSR06-W User Manual Page 21 (24) 11. Dimensional Drawings/Front View ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... -
Page 22: Notes
Rectifier PSR06-W User Manual Page 22 (24) 12. Notes ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1... - Page 23 Rectifier PSR06-W User Manual Page 23 (24) Notes ELTEK VALERE DEUTSCHLAND ©2009 UM_PSR06-W_E_R1.1...
- Page 24 Supplier: Eltek Valere Deutschland GmbH Industrial Division Schillerstraße 16 D-32052 Herford + 49 (0) 5221 1708-210 + 49 (0) 5221 1708-222 Email Info.industrial@eltekvalere.com Internet http://www.eltekvalere.com © Copyright ELTEK VALERE DEUTSCHLAND GmbH 2009. All rights reserved.
