3600 Series Flat Panel Industrial PC
Feature
Parallel Port
COM Ports
Keyboard Port
Mouse Port
Video Port
USB
Ethernet Port
Removable
CompactFlash™
access
(optional)*
9000-XBAY
connector port
(optional)*
* This port can be used for the removable CompactFlash™ or the external bay connector
but not both. If the user chooses one of these options, it must be factory installed.
Table 1-3. 3600 System I/O Panel
Description
The parallel printer port (LPT1) is a DB-25 pin female connector. This
port provides a standard PC-compatible printer interface.
COM1 is RS-232/485 compatible. RS/232 is connected to the lower
9-pin stacked DB connector. The top part of this stack is the RS/485
version of the same port. Since these connectors are attached to the
same port, only one can be used at a time. COM2 is the male 25-pin
DB connector. An external push-button reset option and alarm feature
is available. Consult the AIM3 CPU manual for the BIOS setting that
controls this option.
The keyboard port is a PS/2
can be attached at the side of the unit. The keyboard port on the side
of the unit is the lower connector.
Warning: To maintain a safe condition, do not use an external
keyboard and/or mouse port when the unit is operating in a
hazardous environment.
The mouse port is a PS/2 stacked mini-DIN that allows you to attach
a mouse at the side of the unit.
Warning: To maintain a safe condition, do not use an external
keyboard and/or mouse port when the unit is operating in a
hazardous environment.
The video port is a 15-pin D-sub VGA connector at the side of the
unit. This connector supports any standard VGA connection. Both the
LCD flat panel and video port are active as a default at boot time if
video display devices are connected to them.
The Universal Serial Bus (USB) is a double-high connector on-board
with a USB port to the off-board connector.
The Ethernet port is an on-board 10/100BASET RJ-45 connector with
LEDs.
This option allows external access to Type I or Type II
CompactFlash™ for solid state storage media.
Note: This feature cannot be used if the removable
CompactFlash™ option was not ordered.
The 9000-XBAY connector port is a factory-installed option that
provides a connection from the 3600 to any two IDE devices used by
the optional 9000-XBAY.
Note: This feature cannot be used if the 9000-XBAY option was
not ordered.
®
stacked mini-DIN so a PC/AT keyboard
