3600 Series Flat Panel Industrial PC
Feature
Front Panel
Diagnostic LEDs
Port Access
74-Key Keypad
Integrated Mouse
Brightness
Adjustment
See Chapter 3, Keypad Utility, for detailed instructions on programming the
keypad.
Table 1-2. 3612/15KPM(T) Front Panel
Description
The front panel has four components: a display; strengthened glass
covering the display; a frame in which the display and the glass are
mounted; and the polyester overlay attached to both the glass and the
frame.
The 3612KPM(T) has a 12.1" TFT LCD flat panel. The 3615KPM(T)
has a 15" TFT LCD flat panel.
The strengthened glass covering the display is intended to withstand
normal operating conditions. In the event of damage to the glass, the
overlay will protect the user from any glass shards.
For more information abut the frame or the overlay, see Chapter 5 –
Troubleshooting.
Following is a description of the LEDs and their meanings:
Power GREEN when the system has power.
Disk GREEN when the computer is accessing the disk drive.
COM GREEN when there is communication activity on one of the
serial ports.
Input GREEN when the unit has a touch screen (LED gets brighter
when a touch input is detected) or a key is pressed.
Fault YELLOW when a configuration error exists.
During power-up, the BIOS checks the hardware configuration against
the configuration stored in the CMOS memory.
The 3600KPM(T) features front panel access to a PS/2
keyboard/mouse port and a USB 1.1 port.
These front access connections on the 3612KPM(T) and
3615KPM(T) are nonincendive circuits and may be used safely in
Class I Division 2, Groups A, B, C, & D and in Class II Division 2,
Groups F & G applications. Please refer to the Hazardous
Locations control drawing on page 36.
The 3600KPM(T) keypad features:
Alpha numeric and control keys
•
40 relegendable function keys
•
All keys re-programmable
•
The 3612KPM(T) & 3615KPM(T) feature a 2-button integrated mouse.
These buttons adjust the brightness of the backlights. The right button
increases the brightness and the left button decreases the brightness.
7
