Appendix C – Pinouts
This appendix provides the pinouts for the keyboard, mouse, LPT1, COM1,
COM2, USB, and VGA connectors. NC indicates No Connection.

Keyboard Port Connector

The following table lists the signal definitions for the keyboard connector. It is a
standard PS/2-compatible connector.

Mouse Port Connector

The following table lists the signal definitions for the PS/2 mini-DIN mouse port
connector.
Table C - 1. Keyboard Connector Pinout
Pin Signal
1A KB_DATA
2A NC
3A GND
4A 5VFUSE
5A KB_CLK
6A NC
Table C - 2. Mouse Connector Pinout
Pin Signal
1B MOUSE_DATA
2B NC
3B GND
4B 5VFUSE
5B MOUSE_CLK
6B NC
65 142214 (F)
