Calibrating The Touch Screen - Xycom 3600 Series 3612T User Manual

3600 Series Flat Panel Industrial PC
When using MS-DOS®, the mouse driver must be loaded before the touch
screen driver if both a mouse and touch screen are to be supported.
For computers running MS-DOS®, you will be installing the driver,
on the Documentation and Support Library CD that shipped with your monitor.
1. Create a directory named "Touch" in the root directory of your C:\ drive
2. Run the file "install.exe" in the TB458 subdirectory and follow the
3. Copy all of the batchfile utilities from the Batch Files subdirectory to C:\
4. Add the command
5. Re-boot your system.
6. Calibrate the touchscreen, following the directions in the next section.
It is recommended that you keep all default setting when installing the driver.
The touch screen drivers are located on the Document and Support Library CD,
which is shipped with you unit. Drivers can also be downloaded from
http://www.xycom.com.
! * ) & *
You need to calibrate the touch screen in the following cases:
•
•
For computers running Windows® 98, NT, 2000, or XP: Before calibrating your
touch screen, Xycom strongly recommends altering the following default settings
in the calibration program.
1. Go to START/PROGRAMS/UPDD/SETTINGS
2. Click on the Calibration tab.
3. Set the Calibration points to 25.
4. Set the Margin Percentage to 1.
If the Margin Percentage is set to 0, the calibration may not be correct at the
edges of the screen, causing the cursor to jump unexpectedly.
. This driver can be found in the "Drivers\Touchscreen" folder
and unzip the files into the folder.
directions. Xycom suggests that you accept all of the defaults.
The cursor does not follow the movement of your finger or pen.
You adjust the size of the video image or change the video mode.
Caution
to your autoexec.bat file.
Caution
Note
24
Chapter 2 – Installation
142214 (F)
