Xycom 3600 Series 3612T User Manual page 52

3600 Series Flat Panel Industrial PC
3612KPM(T) F/A Key LED Off (Function Mode)
3615KPM(T)
Description Keyboard
of Key Equivalent
Left Start Mouse click
(windows
start menu)
Explorer Mouse click
(windows
pop-up
menu)
1
: Use the keyboard buttons located on the left side of the keyboard, i.e. the buttons normally used with
the alpha keys
2
: Use the keyboard buttons located on the right side of the keyboard, i.e. the buttons normally used with
the numeric keys
NOTES:
•
F11-F20 = SHIFT F1-F10
•
F21-F30 = CTRL F1-F10
•
F31-F40 = ALT F1-F10
•
END, LEFT START, and EXPLORE keys are available.
Table 3-6. Default Keypad Keycodes
Make Break Codes
Codes
E0 12 E0 1F E0 F0 1F E0 F0 12
E0 12 E0 2F E0 F0 2F E0 F0 12
47
Chapter 3 – Keypad Utility Program
F/A Key LED On (Alpha Mode)
Keyboard Make
Equivalent Codes
E0 12 E0 1F
E0 12 E0 2F
Break Codes
E0 F0 1F E0 F0 12
E0 F0 2F E0 F0 12
142214 (F)
