Reference
Information
This section describes mounting options and the defeatable auto power-down timer.
•
•
Mounting of the NetPA AT
The NetPA AT can be mounted in the following ways:
•
•
•
The half rack width, 9.5 inch (24.1 cm) deep enclosure is designed for inconspicuous
under-table placement using the UTS Series Under Table Shelf System or MBU 125 Low-
Profile Mount Kit, available separately.

Tabletop Use

Each NetPA AT is supplied with rubber feet (not installed). For tabletop use, attach a
self-adhesive rubber foot to each corner of the bottom of the unit.

UL Rack Mounting Guidelines

The following Underwriters Laboratories (UL) guidelines pertain to the safe installation of the
NetPA AT in a rack.
1.
2.
3.
4.
5.
Mounting of the NetPA AT
Defeatable Auto Power-down Timer
Set on a table,
Mounted on a rack shelf,
Mounted under a desk or tabletop.
Elevated operating ambient temperature — If the equipment is installed in a closed
or multi-unit rack assembly, the operating ambient temperature of the rack environment
may be greater than room ambient temperature. Therefore, consider installing the
equipment in an environment compatible with the maximum ambient temperature (TMA)
specified by the manufacturer.
Reduced air flow — Install the equipment in a rack so that the amount of air flow
required for safe operation of the equipment is not compromised.
Mechanical loading — Mount the equipment in the rack so that a hazardous
condition is not achieved due to uneven mechanical loading.
Circuit overloading — Connect the equipment to the supply circuit and consider the
effect that circuit overloading might have on overcurrent protection and supply wiring.
Appropriate consideration of equipment nameplate ratings should be used when
addressing this concern.
Reliable earthing (grounding) — Maintain reliable grounding of rack-mounted
equipment. Pay particular attention to supply connections other than direct connections
to the branch circuit (such as the use of power strips).
NetPA AT Series User Guide • Reference Information 30
