HDMI DA2 Specifications

Accessories and Part Numbers
HDMI DA2 Specifications
NOTE: *Appropriate HDMI to DVI-D cables or adapters are required for DVI signal input/output.
Video
Maximum data rate ..................... Up to 6.75 Gbps (2.25 Gbps per color)
Maximum pixel clock ................... 165 MHz
Resolution range ......................... Up to 1920x1200 or 1080p @ 60Hz, 12-bit color
Formats ....................................... RGB and YCbCr digital video
Standards .................................... DVI 1.0, HDMI, HDCP
Video input
Number/signal type ..................... (1) single link HDMI
Connectors .................................. (1) Female 19-pin HDMI Type A
Input cable length ....................... Up to 50' (15 m) with 1080p @60 Hz, 8-bit color
NOTE: The transmission distance varies greatly depending on the signal resolution and on the type of
cable, graphics card, and display used in the system.
Video output
Number/signal type ..................... (2) single link HDMI
Connectors .................................. (2) Female 19-pin HDMI Type A
Control
Serial control port ........................ RS-232, 3.5 mm, 3-pole captive screw connector
Baud rate and protocol ................ 9600 baud, 8 data bits, 1 stop bit, non-parity
Serial pin configuration ................ 1 = Tx, 2 = Rx, 3 = GND
USB control port .......................... (1) front panel female mini USB B
USB standards ............................. USB 2.0, low speed
Program control .......................... Extron Simple Instruction Set (SIS)
Up to 25' (7.5 m) with1080p @60 Hz, 12-bit color
