This section discusses the specifications, part numbers, and accessories for the
FOX DA8 Plus. Topics that are covered include:
•
•
•

Specifications

Optical specifications
NOTE:
These amplifiers are class 1 laser products. They meet the safety regulations of IEC-60825,
FDA 21 CFR 1040.10, and FDA 21 CFR 1040.11.
Routing .......................................... (1) 1 x 8, (2) 1 x 4, or (4) 1 x 2, selectable
Number/type
Input ....................................... 1, 2, or 4 singlemode or multimode fiber optic
Output .................................... 8, 4, or 2 singlemode or multimode fiber optic
Connectors .................................... 8 LC connectors
Operating distance
Singlemode ............................. 30 km (18.75 miles) with singlemode (SM) cables with an Extron singlemode Tx/Rx
Multimode ............................... 300 m (985') with 62.5 µm OM1 multimode (MM) cables with an Extron multimode
NOTE:
Operating distance is approximate. These are typical distances. The maximum distance may be greater than
these typical numbers depending on factors such as fiber type, fiber bandwidth, connector splicing, losses,
modal or chromatic dispersion, environmental factors, and kinks.
Nominal peak wavelength .............. 850 nm for MM model, 1310 nm for SM model
Data rate ........................................ 4.25 Gbps
Transmission power
Singlemode ............................. -5 dBm, typical
Multimode ............................... -5 dBm, typical
Maximum receiver sensitivity
Singlemode ............................. -18 dBm, typical
Multimode ............................... -12 dBm, typical
Optical loss budget
Singlemode ............................. 13 dB, maximum
Multimode ............................... 7 dB, maximum
Specifications
Part Numbers and Accessories
Mounting the Unit
unit
Tx/Rx unit
1 km (3280') with 50 µm OM2 multimode (MM) cables with an Extron multimode Tx/Rx
unit
2 km (6561') with 50 µm OM3/OM4 2000 MHz bandwidth laser multimode cable
with an Extron multimode Tx/Rx unit
FOX DA8 Plus • Reference Information 19
