Param. output

Parametric output strategy can be used to perform specific functions like alternator control, electric
pumps, electric blow off valve, variable intake manifold length etc.
Parametric Output 1 has 3 conditions that control the state of the output, the other parametric
outputs have only 2 conditions. These conditions can be combined with logical operators OR /
AND.
PARAMETER
Output
Invert output
Variable #X type
Variable #X operator
Variable #X value
Variable #X hysteresis
Logical operator 1
Enable cycling
Cycling on time
Cycling off time
Cycle once
DESCRIPTION
Device output to control with the parametric output strategy
Reversal of output state
The first condition variable: RPM, MAP, TPS, IAT, CTL, VSS, analog
input voltage Analog In#, Oil pressure, Oil temperature, Fuel pressure,
battery voltage
Mathematical operator of the condition to change the state of the
output: GREATER THAN , LOWER THAN , EQUAL OR GREATER
THAN, LOWER THAN OR EQUAL
The value on which the output depends (unit depends on the variable
type)
Hysteresis limit value at which it will return to its original state
Option adds next condition with logical operator "OR" "AND"
Turns cyclic operation
The time for which the output will be active
The time for which the output is not active
Option turn of cycling after one cycle
Page 91
