Scope

ECUMASTER EMU has built in scope tool that allows measurement of signals present at primary
trigger, CAM#1 and CAM#2 inputs. By using this tool it is possible to determine the trigger pattern
for crankshaft and camshafts trigger wheels, to check if the polarity of the signal is correct and to
save the trace for further analysis or for our technical support for troubleshooting.
For correct reading the signal, primary trigger input is required. To activate scope functionality, the
option 'enable scope' need to be checked in Primary trigger configuration window. The scope tool
is available in log/Scope options.
To take scope trace, during engine operation (cranking or running) the blue arrow should be
pressed (or CTRL+SPACE short-cut). Additional data is shown for selected region for analysis
purpose.
t
ts
te
dt
RPM
NE
ICON
SHORT-CUT
Q
A
CTRL + SPACE
SELECETD AREA DATA DESCRIPTION
Current scope trace time
The time of selection start
The time of selection end
Selection length (te - ts)
Theoretical engine RPM for selected area
Number of trigger edges for selected area
ICONS DESCRIPTION
DESCRIPTION
Open scope trace file from disk... (*.emuscp)
Save scope trace to disk... (*.emuscp)
Zoom in the scope trace
Zoom out the the scope trace
Download scope trace from device
Context help window
DEFAULT KEYBOARD SHORT-CUTS
DESCRIPTION
Zoom in the scope trace
Zoom out the the scope trace
Download scope trace from device
Page 29
