Status bar

Status bar shows the most important parameters of EMU device to allow easy trace of them.
Connection status
Ignition status
STATE
TBL SET
CAN BUS
CEL
FW VER
LC
FC
SC
ALS
KS
RAL
IDL
PO1-PO4
DESCRIPTION OF STATUS BAR
DISCONNECTED - there is no communication with EMU device
CONNECTED - communication with EMU device established
Information about synchronization of ignition system
NO SYNC – no synchronization
SYNCHRONISING – trying to synchronize
SYNCHRONISED – ignition system synchronized
Current state of the EMU device
INACTIVE - there are no calculations connected to fuelling and
ignition system
CRANKING - in this state fuel dose is taken directly from Cranking
fuel table, and ignition angle is defined by Cranking ignition angle
parameter
AFTERSTART - the engine is running, Afterstart enrichment is present
RUNNING - the engine is running normally
Information about current tables set
Current state of CAN BUS module
BUS OK - CAN BUS module works correctly
MODULE DISCONNECTED
extension port
BUS ERROR - CAN BUS error (inappropriate speed, wrong
connection, termination problems)
Information about "check engine light"
Firmware version of connected EMU device
Launch control strategy active
Fuel cut
Spark cut
ALS strategy active
Knocking occurs
Rolling antilag strategy active
Idle control strategy active
Parametric outputs state
Page 30
- CAN BUS module is not connected to
