X axis bins wizard
PARAMETER
Load min value
Load max value
Interpolation type

RPM bins wizard

This wizard is used for automatic generation of set points
for the load axis (X).
DESCRIPTION
Minimal value for axis X
Maximal value for axis X
The way of dividing set points on axis X between the minimal and maximal
value. We have 3 options to choose from:
Linear interpolation – linear interpolation between values
Exponential interpolation 1 – exponential interpolation, version 1
Exponential interpolation 2 – exponential interpolation, version 2
Wizard of RPM values for scale Y acts identically as
wizard for axis X.
