Check engine

Check engine function is used to indicate possible sensor failures detected by EMU device.
PARAMETER
Check engine light output
Invert output
Report failure of WBO sensor
Report failure of IAT sensor
Report failure of CLT sensor
Report failure of MAP sensor
Report failure of EGT1 sensor
Report failure of EGT2 sensor
Report EGT alarm
Report knocking
Report failure of FlexFuel senosr
Report failure of DBW
Report fuel pressure failure

EGT Alarm

EGT function is used to indicate overrun of defined exhaust gas temperature. In the case of two
sensors it is possible to define which sensor should be used for alarm function. There is also an
option to indicate temperature overrun using check engine light. To activate this feature in options
Check Engine/Report EGT alarm should be checked.
PARAMETR
Alarm type
Alarm output
Invert output
EGT temperature
DESCRIPTION
Output used for indication device (LED, bulb, buzzer, etc.)
Invert output state (can be used to test indicator)
Oxygen sensor circuit malfunction
Intake air temperature sensor (IAT) circuit malfunction
Coolant temperature sensor (CLT) circuit malfunction
Manifold
malfunction
Exhaust gas temperature sensor #1 circuit malfunction
Exhaust gas temperature sensor #2 circuit malfunction
Excessive exhaust gas temperature
Knock sensor alert
FlexFuel sensor circuit malfunction
Electronic throttle circuit malfunction
Fuel pressure alert
DESCRIPTION
Selection of EGT sensor(s) that should be used for alarm
The output for
In the case of using Check Engine / Report EGT alarm option, this
output could be unassigned
Inverting of output state (could be used for testing output)
The alarm temperature limit
Page 118
absolute pressure
indicator device
sensor (MAP) circuit
(LED, buzzer, etc.).
