Enable temp. correction Activate fuel dose correction in function of fuel temperature
Error frequency
Fail safe Ethanol
content
Fail safe temperature
Sensor calibration
Sensor calibration table is used to define fuel ethanol content as a function of FlexFuel sensor
signal frequency. For GM/Continental sensors, ethanol content at 50Hz is 0% and 100% at 150Hz.
Tables blend
Interpolation between tables based on ethanol content is available for the flowing maps: VE, IGN,
AFR, Boost, Crank fuel, ASE.
corresponding blending table (eg. VE Blend for VE table). The final value is calculated as follow::
Value = Tbl1[] * Blending% + Tbl2[] * (100% - Blending%)
If the frequency of the FlexFuel sensor is greater or equal Error
frequency, the sensor is not working correctly. In such cases the
check engine light can be enabled (Check engine) and the value from
the Fail safe Ethanol content parameter is used
The fail safe value of ethanol content in the case of FlexFuel sensor
failure
The fail safe value of fuel temperature in the case of FlexFuel sensor
failure
The blending factor between the tables is defined with
Page 105
