Tables switch

Tables switch options are used to define how the tables will be change. The tables that can be
switched have suffix #1 and #2. Tables can be change via switch or automatically when the VTEC
option is activated. There is also an option to interpolate between tables based on external signal
such as fuel ethanol content from FlexFuel sensor readings. In the case of boost tables switching it
is defined in Boost/Parameters options.
Information about current table set can be found on the application status bar (TBL SET).
PARAMETER
Tables switch mode
Tables switch input
Switch VE table
Switch IGN table
Switch AFR table
Switch CAM #1 table
Switch CAM #2 table
Switch cranking fuel
Switch warmup
enrichment
DESCRIPTION
Do not switch tables - table switch function is disabled
Switch with user input - switching tables using switch connected to
one of the EMU inputs
VTEC Switch - automatic switch when the VTEC solenoid is activated
FlexFuel blend - dual tables are used for interpolation based on
FlexFuel configuration
The EMU input used for tables switch. More information about
switches can be found in User switches section
Activation of switching VE tables
Activation of switching IGN tables
Activation of switching AFR tables
Activation of switching VVTi tables for CAM #1
Activation of switching VVTi tables for CAM #2
Activation of switching Cranking fuel tables
Activation of switching Warmup enrichment tables
