VTEC

VTEC control parameters are used for controlling variable timing and lift of the valves using on/off
type solenoid. There is an option to automatic switch tables when the solenoid state changes. To
do this in parameters Tables Switch/Table switch mode option VTEC Switch must be enabled.
Activation of VTEC control solenoid can be defined by two non-continuous areas, in ranges of
RPM, TPS and intake manifold pressure (MAP).
PARAMETER
VTEC Output
Invert output
RPM Min/Max
RPM Hist.
MAP Min/Max
MAP Hist
TPS Min / Max
TPS Hist
VSS Min
VSS Hist
DESCRIPTION
The EMU output used for VTEC control solenoid
Inverting the output state
The range of RPM that is used for activation of VTEC control solenoid
RPM range hysteresis
The range of MAP sensor values that is used for activation of VTEC
control solenoid
MAP range hysteresis
The range of throttle position that is used for activation of VTEC
control solenoid
TPS range hysteresis
The minimum vehicle speed for activation of VTEC control solenoid
Speed hysteresis
