7 Removal and replacement procedures

IMPORTANT:
If a cooling fan or power supply fails, you must replace it. Replacement usually takes no longer
than 5 minutes. For instructions on replacing these components, see
hot-swap fan" (page 101)

Server components list

IMPORTANT:
correct part from HP Partsurfer (http://www.partsurfer.hp.com/search.aspx).
To select a replacement part from the full component list, enter the product number for your system.
Table 37 CRU list
Processors
Intel Itanium 1.6-GHz Dual-core processor 10-MB cache
Intel Itanium 1.46-GHz Quad-core processor 16-MB cache
Intel Itanium 1.6-GHz Quad-core processor 20-MB cache
Replacement, Processor heat sink
Memory (DIMMs)
DDR3 Memory Module 2 GB
DDR3 Memory Module 4 GB
DDR3 Memory Module 8 GB
DDR3 Memory Module 16 GB
Power supply
-48VDC Hot Plug Power Supply
Internal disks and removable media
72-GB/15K 2.5" SAS hard disk drive
146-GB/10K 2.5" SAS hard disk drive
146-GB/15K 2.5" SAS hard disk drive
300-GB/10K 2.5" SAS hard disk drive
450-GB/10k 2.5" SAS 6Gb Hard Disk Drive
600-GB/10k 2.5" SAS 6Gb Hard Disk Drive
HP DVD ROM slimline
HP DVD+RW slimline
Risers
PCIe IO Riser, 3 PCI-Express slots; 1 x8, 2 x4
PCA, Memory Riser
Boards
Replacing the fans and power supplies
and "Removing and replacing a hot-swap power supply" (page
Part numbers are found by using the part nomenclature from this list to select the
Description
1
"Removing and replacing a
Spare part number
AH339-6914A
AH339-6915A
AH395-67004
AM326-69001
AM327-69001
AM328-69001
AM363-69001
451816-001
512743-001
507283-001
512744-001
507284-001
581310-001
58131 1-001
AM242-6700A
AM243-6700A
496057-001
AH395-69002
Server components list
98).
91
