1 Overview

Table 2 Hardware specifications for the server
Component
Processors
Memory
Disk drives
PCI slots
SAS controller
LAN ports
Management ports
Optical drive
Power supplies
8 Overview
One or two Itanium Dual-Core or Quad-Core processors:
1.6-GHz Dual-Core processor 10-MB cache
1.46-GHz Quad-Core processor 16-MB cache
1.6-GHz Quad-Core processor 20-MB cache
Supports up to twenty-four Double Data Rate 3 (DDR3) DIMMs mounted on risers that attach
to the system board
Supported DIMM sizes are as follows:
◦
2 GB
◦
4 GB
◦
8 GB
◦
16 GB
Minimum memory configuration is 4 GB (2 x 2-GB DIMMs).
Maximum memory configuration is 384 GB (24 x 16 GB DIMMs).
NOTE: For additional restrictions on memory configuration, see Installing DIMMS
DIMMs" (page 49).
One to eight hot-plug SAS hard drives
I/O riser options:
One full height full length PCIe x8 and two low profile PCIe x4 slots
One full height full length PCIe x8 and one low profile PCIe x8 slots
Eight port SAS controller or eight port SAS controller with internal RAID
Four GigE LAN ports
One serial port, four USB 2.0 ports, one 1G/100/10 LAN port, and two VGA ports
NOTE: The serial port is intended primarily for use as a serial console port. The port can be
configured through iLO 3 for use with other serial devices (subject to OS and device limitations
and dependencies). If the server is disconnected from DC power or if the iLO is reset by the
iLO Physical Presence button, the serial port reverts to console mode settings.
One SATA DVD+RW drive
Two 1200W 48VDC hot-plug power supplies
Server
"Installing
