Removing And Replacing A Hot-Plug Sas Hard Drive; Removing And Replacing A Power Supply Blank - HP Carrier-Grade rx2800 i2 Server DC User's & Service Manual

Remove the component as indicated.
Figure 13 Hard drive filler removal
To replace the blank, slide the blank into the bay until it locks into place.

Removing and replacing a hot-plug SAS hard drive

The server supports up to eight SFF, 2.5-inch SAS hard drives. Each drive is equipped with two
LEDs that indicate activity and device status.
To remove the component:
CAUTION:
expansion slot covers, or blanks installed. If the server supports hot-plug components, minimize the
amount of time the access panel is open.
1. Determine the status of the hard drive from the hot-plug SAS hard drive LED combinations.
2. Back up all server data on the hard drive.
3. Remove the hard drive.
To replace the component, see

Removing and replacing a power supply blank

To remove the component:
CAUTION:
all bays are populated with a component.
To remove the component:
For proper cooling do not operate the server without the access panel, baffles,
"Installing a hot-pluggable SAS hard drive" (page
To prevent improper cooling and thermal damage, do not operate the server unless
Removing and replacing a hot-plug SAS hard drive
41).
97
