NOTE:
are supported:
–
–
–
Example configurations of eight disks with zero memory
–
–
–
–
–
–
–
–
Full feature
◦
RAID 0, 10, 5
◦
Cache needed and installing it automatically enables the full feature firmware stack.
Super capacitor is optional.
Advanced pack
◦
RAID 6, 50, 60
◦
Cache needed. Advanced Pack license must be entered to enable. Super capacitor is
required.
To enable Advanced Pack licensing, see

Controls and ports

Front panel controls and ports

Figure 4 Front panel components
Quick release levers
1
iLO 3 information pull tab
2
SID
3
12 Overview
To use all 8 disks with the zero memory option, the following RAID configurations
RAID 0: 1 or 2 LUNs striped with up to 8 disks
RAID 10: 1 or 2 LUNs striped and mirrored with even number of up to 8 disks
RAID 1: 1 LUN using 2 mirrored disks, and one additional LUN in RAID 0 or 10
LUN 1: RAID 1 bays 1 and 2
LUN 2: RAID 0 bays 3, 4, 5, 6, and 7
Hot Spare: bay 8
LUN 1: RAID 10 bays 1, 2, 3, and 4
LUN 2: RAID 10 bays 5, 6, 7, and 8
LUN 1: RAID 0 bays 1, 2, and 3
LUN 2: RAID 10 bays 5, 6, 7, and 8
Hot Spare: bay 4
"Adding a RAID Advanced Pack license key" (page
Hard drive bays
5
USB connectors
6
Video connector
7
133).
