Processor load order

The server holds up to two dual-core or quad-core processors on the system board. The sockets on
the system board are labeled Module 0 and Module 1. If the server has only one processor, it is
installed in socket 0. Install the second processor in socket 1.
See Figure 2 (page 10)
Table 7 Processor load order
Processor
0
1

Installing a processor and heat sink module

CAUTION:
replacing the system board.
CAUTION:
pulled fully out before installation.
CAUTION:
touch the bottom of the processor, especially the contact area.
CAUTION:
configurations must contain processors with the same part number.
CAUTION:
from the heat sink after assembling.
The processor and heat sink ship as separate units and are coupled during installation into the
server.
1. Open the processor cage.
2. Remove the processor airflow baffle.
for the processor socket numbers.
Socket
Module 0
Module 1
The pins on the processor socket are very fragile. Any damage to them might require
To avoid damage to the processor, verify that the plastic tabs on the processor are
To avoid damage to the processor, handle the processor only by the edges. Do not
To prevent possible server malfunction and damage to the equipment, multiprocessor
To prevent thermal instability and damage to the server, do not separate the processor
Installing a processor 51
