Removal and replacement procedures

Required tools

You need the following items for some procedures:
•
T-15 Torx screwdriver (provided inside the server blade)
•
T-5 Torx screwdriver
•
HP Insight Diagnostics software

Safety considerations

Before performing service procedures, review all the safety information.

Preventing electrostatic discharge

To prevent damaging the system, be aware of the precautions you need to follow when setting up the
system or handling parts. A discharge of static electricity from a finger or other conductor may damage
system boards or other static-sensitive devices. This type of damage may reduce the life expectancy of the
device.
To prevent electrostatic damage:
•
Avoid hand contact by transporting and storing products in static-safe containers.
•
Keep electrostatic-sensitive parts in their containers until they arrive at static-free workstations.
•
Place parts on a grounded surface before removing them from their containers.
•
Avoid touching pins, leads, or circuitry.
•
Always be properly grounded when touching a static-sensitive component or assembly.

Server blade warnings and cautions

WARNING:
server blade access panel when power is applied through the HP ProLiant p-Class diagnostic
station. Remove all power from the server blade before removing the access panel.
WARNING:
remove the server blade access panel while the server blade is installed in the server blade
enclosure. Do not remove the server blade access panel and then install the server blade into
the server blade enclosure.
WARNING:
internal system components to cool before touching them.
All manuals and user guides at all-guides.com
("HP Insight
To reduce the risk of injury from high-current electrical energy, do not remove the
To reduce the risk of shock or injury from high-current electrical energy, do not
To reduce the risk of personal injury from hot surfaces, allow the drives and the
Diagnostics" on page 68)
Removal and replacement procedures 25
