GE MM300 Manual page 145

CHAPTER 4: FIELDBUS INTERFACE
MM300 MOTOR MANAGEMENT SYSTEM – COMMUNICATIONS GUIDE
ATTRIBUTE DESCRIPTION
(HEX VALUE)
0D Starter Type
0E Motor FLA
0F High Speed FLA
10 Motor Name Plate Voltage
11 Change Over Current
12 Transfer Time
13 High Speed Start Block
14 Ramp Up Time
15 Ramp Down Time
16 Precontactor Time
17 Motor Rating
18 High Speed Motor Rating
19 IL Ignore In Test
1A IL A Function
1B IL A Inst Alarm
1C IL A Startup Override
1D IL A Running Override
1E IL A Healthy State
1F IL B Function
20 IL B Inst Alarm
21 IL B Startup Override
22 IL B Running Override
23 IL B Healthy State
24 Comms Ok Evaluation
25 Overload Pickup Level
26 Unbalance K Factor
27 Cool Time Constant
Running
28 Cool Time Constant
Stopped
29 Hot Cold Safe Stall Ratio
2A Thermal Capacity Alarm
Level
2B Standard Overload Curve
2C Reserved
2D Mechanical Jam Level
2E Mechanical Jam Delay
2F Acceleration Alarm Timer
30 Acceleration Trip Timer
31 Current Unbalance Alarm
Level
32 Current Unbalance Alarm
Delay
33 Current Unbalance Trip
Level
34 Current Unbalance Trip
Delay
UNIT FORMA MI MAX
T CODE N
None FC139 0 7
Amps F2B 5 10001
Amps F2B 5 10001
Volts F1 100 690
FLA F2B 10 51
Seconds F1 0 125
None FC126 0 1
Seconds F1 0 125
Seconds F1 0 125
Seconds F1 0 60
Kw F2B 3 11001
Kw F2B 3 11001
None FC126 0 1
None FC140 0 3
None FC126 0 1
Seconds F1 0 3600
Seconds F1B 0 3601
None FC116 0 1
None FC140 0 3
None FC126 0 1
Seconds F1 0 3600
Seconds F1B 0 3601
None FC116 0 1
None FC131 1 64
FLA F3 101 125
None F1 0 19
Mins F1 1 1000
Mins F1 1 1000
Percent F1 1 100
Percent F1B 10 101
None F1 1 15
FLA F3B 101 451
Seconds F2 1 300
Seconds F2B 5 2501
Seconds F2B 5 2501
Percent F1B 4 41
Seconds F1 1 60
Percent F1B 4 41
Seconds F1 1 60
DEVICENET PROTOCOL
FACTOR SIZE IN
Y BYTES
DEFAUL
T
0 2
10001 2
10001 2
690 2
15 2
1 2
1 2
1 2
1 2
0 2
11001 2
11001 2
0 2
0 2
0 2
0 2
0 2
1 2
0 2
0 2
0 2
0 2
1 2
1 2
101 2
0 2
15 2
30 2
75 2
101 2
4 2
451 2
1 2
2501 2
2501 2
15 2
1 2
30 2
1 2
4–67
