CHAPTER 4: FIELDBUS INTERFACE
MM300 MOTOR MANAGEMENT SYSTEM – COMMUNICATIONS GUIDE
Table 4-22: Motor Data Object, Class Code A0h, Attributes:
ATTRIBUTE
NAME/DESCRIPTION
ACCESS
01H
Get
Revision of Motor Data Object
Table 4-23: Motor Data Object, Class Code A0h, Instance 01h, Attributes, Get Access:
NAME/DESCRIPTION
ATTRIBUTE
01H
Motor Data
02H
Digital Data
03H
Summary of Motor Data
04H
Reserved
05H
Motor status
06H
Motor load (%)
07H
Cause of last trip
08H
Thermal capacity used (%)
09H
Current metering
0AH
Average Line Voltage (V)
0BH
Power metering
0CH
Contact Input Status
0DH
Contact Output Status
0EH
RTD metering
DATA FORMAT, SUMMARY OF MOTOR DATA
ITEM DESCRIPTION
Motor status
Motor load (%)
Cause of last trip
Thermal capacity used (%)
DATA FORMAT, MOTOR DATA
ITEM DESCRIPTION
Motor status
Motor load (%)
Cause of last trip
Thermal capacity used (%)
Average phase current (A)
Ground current (A)
Average Line Voltage (V)
Real power (kW)
Power factor
Contact Input Status
Contact Output Status
Local hottest RTD number
Local hottest RTD temperature
DEVICENET PROTOCOL
DATA
TYPE
UINT
SIZE IN
BYTES
38
9
7
NA
1
2
2
2
8
2
6
8
4
3
SIZE IN BYTES
FORMAT
1
FC129 (low byte only)
2
F1
2
FC134
2
F1
SIZE IN BYTES
FORMAT
1
FC129 (low byte only)
2
F1
2
FC134
2
F1
4
F10
4
F10
2
F1
4
F13
2
F21
8
BIT per input
4
BIT per output
1
Unsigned 8 bit integer
2
F4
VALUE
1
FORMAT
See below
See below
See below
NA
FC129 (low byte
only)
F1
FC134
F1
See below
F1
See below
BIT per input
BIT per output
See below
4–65
