DEVICENET PROTOCOL
NOTE:
NOTE

DeviceNet power supply configuration

NOTE:
NOTE
4–42
Table 4-9: Fieldbus interface external connections (DeviceNet)
Path Connection (external)
V– Pin 3, CAN_GND
L Pin 2, CAN_L
C Pin 5, CAN_SHLD
H Pin 7, CAN_H
V+ Pin 9, CAN_V
The module status (MS) and network status (NS) LEDs indicate the status of the Fieldbus
interface.
Table 4-10: DeviceNet LED indications
LED LED operation
MS Green on, red on, green on
Flashing green
Green on
Flashing red
Red on
NS Flashing green
Green on
Flashing red
Red on
Red and green
When used for DeviceNet, the fieldbus port has the following characteristics.
• Baud rate: 125, 250, and 500 kbps
• MAC ID: 0 to 63
• Vendor ID: 928
• Product Code: 0x4D42
• Message types: poll, and explicit messaging
The ODVA cable assembly length (0.4 meter) must be considered in calculating the network
drop length budget to the node.
The DeviceNet port uses external voltage to power the electronics. The figures below show
the configuration of the comms board option/power supply switch.
Devicenet supports external power only.
Figure 4-10: Comms board power supply configuration
ON
1 2 3 4 5 6 7 8
= switch position
Wire color
Black
Blue
Bare
White
Red
Description
Device self-test
Device in standby state
Device operational
Recoverable fault
Unrecoverable fault
Online, not connected
Online, connected
Connection timeout
Critical link failure
Network access detected
DEVICENET WITH EXTERNAL SUPPLY
MM300 MOTOR MANAGEMENT SYSTEM – COMMUNICATIONS GUIDE
CHAPTER 4: FIELDBUS INTERFACE
853846A1.CDR
