SummaCut cutter

6.3.4 PERFORMANCE

Cutting specifications on 0.05 mm (0.002") wax-backed vinyl, total media thickness not
greater than 0.25 mm (0.010")
Axial speed
Maximum Speed
Default speed
Axial Acceleration
Max. Acceleration
Addressable resolution
Default resolution
Mechanical resolution
Repeatability*
Accuracy*
Knife pressure
Pen pressure
Pouncing pressure
* Valid within the guaranteed tracking length (see table 3). Not valid in 'Oversized' Mode.
** Excludes differences due to media expansion, stretching, etc.

6.3.5 INTERFACE

Communication
Serial : I/O Port connector
Mating connector
Byte format
Baud rate
USB : I/O Port connector
Mating connector
Buffer Size

6.3.6 FIRMWARE

Language
Supported character sets
Supported fonts
ROM-based plots
Specifications
50 to 800 mm/s
Up to 1131 mm/s diagonal
700 mm/s
0.025 mm, 0.1 mm
0.025 mm
0.0127 mm
+/- 0.1mm
0.2% of move or 0.25 mm, whichever is
greater **
TABLE 5:
SUMMACUT PERFORMANCES
Standard asynchronous RS-232-C and
Universal Serial Bus .
DB-9P
DB-9S
8 data bits, 2 stop bits, no parity
57600, 38400, 19200, 9600, 4800, 2400 bps
USB series "B" receptacle
USB series "B" plug
16 MB
TABLE 6:
SUMMACUT INTERFACE SPECIFICATIONS
DM/PL, HP-GL (758x emulation), HP-GL/2
Standard ASCII
Sans serif (single stroke & medium)
Confidence plot, DIN plot
TABLE 7:
SUMMACUT FIRMWARE
User's Manual
2 to 32 ips
Up to 44 ips diagonal
28 ips
up to 2 G
up to 3 G diagonal
0.001", 0.005"
0.001"
0.0005"
+/- 0.004"
0.2% of move or 0.010", whichever
is greater **
0 to 400 gr.
0 to 400 gr.
0 to 250 gr.
6-6
