2 Basic Operation

2.1 LCD AND CONTROL PANEL

The liquid crystal display (LCD) contains one line of 16 characters. The LCD provides cutter
status information during operations and displays menu options for the configuration of
the cutter.
FIG 2-1
2-1

TOUCH SCREEN

The liquid crystal display (LCD) contains one line of 16 characters. The LCD provides cutter
status information during operations and displays menu options for the configuration of
the cutter.
The various menu and submenu items are always presented in a loop, which means that,
when the last menu or submenu item is displayed, pressing the appropriate key will
automatically take you back to the first item of the same menu or submenu.
NOTE: A parameter or parameter value preceded with an asterisk (*) is the current selected
parameter or parameter value. If a menu is left with a value on the LCD which is not
preceded by an asterisk, then this will not be the saved value.
Each keystroke can initiate an internal test or movement of head or media.
WARNING
KEEP FINGERS AND OTHER BODY PARTS AWAY FROM THE CUTTING AREA. THERE
ARE HAZARDOUS MOVING PARTS.
Basic Operation 2-1
