SummaCut cutter
7. Use , ,
should be at least 3 by 3 cm or 1" by 1").
8. Press to confirm.
The cutter will make a circular movement while it measures the reflection of the media. It will
briefly display the measured values and display the message "put sensor on black area."
9. Use , ,
(approximately in the middle and slightly to the bottom right).
10. Press to confirm.
The cutter will make a circular movement while it measures the reflection of the marker
color. It will briefly display the measured values, then it will show a value that is
characteristic for this media color – marker color combination. Store this value for future
reference.
NOTE: An error message may appear if the sensor is not able to differentiate between black
and white. Make sure that the test has been performed correctly. If OPOS is not able to
sense the markers, one of the manual alignment methods (see Error! Reference source not
found..) must be used.
Contour Cutting
and to maneuver the knife on top of a white area (the area
and to maneuver the knife on top of a black area
User's Manual
3-4
