3.2.1 OPOS calibration

1. Switch the cutter on and load black vinyl with white backing.
NOTE: Black vinyl with white backing MUST be used when calibrating OPOS. Media
calibration setting must be set to default value.
2. Set the head's origin above a clean, blank part of the vinyl.
3. Press .
'Velocity' will appear on the LCD.
4. Press .
'System Setup' will appear on the LCD.
5. Press .
'Confidence' will appear on the LCD.
6. Use or to scroll through the menu until 'Cal OPOS' is reached, press
The cutter will cut out a square measuring approximately 9.5x9.5mm and move the square
forward. "Weed Rectangle" will appear on the display.
7. Carefully weed the square, making sure the edges stay intact. Press
OPOS will read the edges of the square and calibrate itself accordingly.
NOTE: In order to keep the accuracy of the OPOS sensor as high as possible, do this
calibration each time the knife is been replaced.
