2.3 How to Set Cutting Speed

The actual speed at which the tool moves is determined by 4 different parameters. Speed
(and acceleration) while the tool is down; speed (and acceleration) while tool is up.
These 4 parameters have been bundled in one parameter to make changing speed fast and
easy.
This overall parameter is called "velocity" and is the speed the cutter uses when the tool is
down. If velocity is raised or lowered, then the other parameters are also raised or lowered
accordingly.
There is one fixed speed: the speed at which the cutter pulls the media from the roll. This
speed is fixed at 200mm/s (8ips).
Setting the cutting speed:
1. Power on the cutter.
2. Press .
'Velocity' will appear on the LCD.
3. Press or
The velocity will change on the LCD.
4. Press to confirm.
An asterisk will appear before the velocity, indicating it is now the selected velocity.
5. Press twice to leave the menu.
Setting the speed parameters separately:
1. Power on the cutter.
2. Press .
'Velocity' will appear on the LCD.
3. Press .
'System Setup' will appear on the LCD.
4. Press .
'Confidence' will appear on the LCD.
5. Use or to scroll through the menu until 'Velocity' is reached, press
Basic Operation
to change the velocity.
User's Manual
.
2-6
