SummaCut cutter

1.4.2 RS-232 Connection

The RS-232 cable should be 5 meters (16 feet) or less in length. The connectors on both
sides are DB-9S type connectors. There is no need to install a device driver when connecting
a cutter with an RS-232 connection.
The parameters of the RS-232 connection must be set in either the properties of the COM
port in the device manager or in the cutting software program itself. Please refer to the
manual for the cutting software on how to set the parameters for the RS-232 connection
with the cutter.
Default settings of the RS-232 connection are listed in the table below.
1-1
Setup
Baud rate 9600
Data Bits 8
Parity none
Stop Bits 2
Flow Control Hardware or XON / XOFF
TABLE 1-1
DEFAULT RS-232 SETTINGS OF THE SUMMACUT CUTTER
User's Manual
1-13
