SummaCut cutter
Changing origin.
1. Press , ,
The media will move to the new origin, values will appear on the LCD. The X value is the
distance from the original origin; the Y value is the maximum cutting width.
2. Press to toggle the Y value between the maximum cutting width and distance
from original origin.
The Y value will toggle.
3. Press if the desired origin is reached.
The cutter comes online and is ready to receive data from the computer.
4. Or press to cancel.
The cutter will move to its original origin and come online.
Extended load.
The function extended load makes it possible to define the limits of the Y axis so that the
cutter can cut outside the pinch rollers. Media has to loaded before this function can be
used.
1. Press until 'extended load' appears on the LCD.
Extended Load will appear on the LCD.
2. Press .
'Origin' will appear on the LCD.
3. Press or
The head will move to its new origin.
4. Press .
'Size' will appear on the LCD.
5. Press or
6. Press .
Note: Tracking is not guaranteed when using this mode.
Setup
and to change the origin.
to define the new right limit (origin).
to define the new left limit
