Arecont Vision AV12275DN-NL Installation Manual page 6

SurroundVideo® O mni G 2
Installation
1. Determine a secure location to mount the camera.
2. Use the supplied security L-key, to loosen the four (4) screws securing the dome cover.
3. Remove the dome cover and protective foam. Do not remove screws from the dome cover.
The SurroundVideo® Omni G2 camera has been designed to provide installers with flexible mounting
options such as ceilings, walls, poles or corners.
NOTE: When mounting the camera outdoors or in a wet environment, use of supplied rubber gasket is
recommended. Ensure the three holes on the top of the housing are aligned with the gasket and it is
properly seated flush with the camera housing.
