SurroundVideo® O mni G 2

Electrical Box Adapter

The AV-EBA electrical box adapter is used to attach the camera to a common single, double or square
electrical box.
1. Using the AV-EBA's supplied machine screws, match the mounting holes on the adapter with
the threaded holes on the electrical box. Ensure every threaded hole is matched with a
mounting hole.
2. Attach the electrical box adapter to the user supplied electrical box.
Figure 1: Attach AV-EBA adapter to common electrical box
