SurroundVideo® O mni G 2

AV IP Utility Focus Tab

Menu
Page | 39 support@arecontvision.com
+1.818.937.0700 877.CAMERA.8
Feature Description
Manual Focus: Numbers indicate the level of focusing in order to adjust the field-of-view.
+20, +5, +1, -
20, -5, -1
To set-up a focus area (if necessary), draw a rectangle with the mouse
(by left-clicking and dragging the mouse to a desired zoom size). To
automatically adjust focus, choose "Full-range Focusing" or "Short-range
Focusing" depending on the image clarity.
Full-range Best for scenes that are completely out of focus. The camera
Focus
automatically scans the full focus range of the scene to find the best
focus position.
Short-range Best for scenes that are slightly of out of focus. The camera quickly fine-
Focus
tunes for a precise focus position.
Stop Stops any command in progress.
Focus Aid The higher the focus aid value means the more the lens is required to focus.
If the focus window box illuminates GREEN, the lens has reached its optimal
focus level.
If the focus window box illuminates RED, the lens is having difficulty reaching an
optimal focus level.
If the focus window box illuminates YELLOW, the focusing of the lens remains
unchanged.
If the focus window box illuminates GREY, the focusing of the lens has been
completed.
