ready for installation.

Use correct screws and do not over tighten screws.

2.3 Setting Jumpers

A jumper is the simplest kind of electric switch. It consists of two metal pins and a cap. When

setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the

jumper cap is placed on both pins, the jumper is SHORT. If you remove the jumper cap, or place

the jumper cap on just one pin, the jumper is OPEN. Please see the following illustrations

The illustrations on the right

show a 2-pin jumper. When the

jumper cap is placed on both

pins, the jumper is SHORT. If

you remove the jumper cap, or

place the jumper cap on just

one pin, the jumper is OPEN.

These illustrations show a

3-pin jumper. Pins 1 and 2 are

SHORT.

EBC 340 User's Manual

Open (Off)

Table 2-1: Setting Jumpers

Short (On)
