1.1

Specification

CPU Support
Intel® Atom™ Processor N270 1.6GHZ
Main Memory
1 x DDR2 SO-DIMM Socket (up to 2GB SO-DIMM memory)
Chipset
Intel 82945GSE Graphic Controller Hub (GMCH)
Intel® 82801GBM ICH7 Mobile (ICH7-M)
Display
Intel® 945GSE integrated 3D graphic engine GMA950
Support Dual Independent Display: CRT+LVDS
CRT: 1 x DB15 VGA CON
LVDS: 1x DF13 20-pin connector
Analog VGA interface:
Resolution up to 1600x1200 at 85 Hz, 2048x1536 at 75Hz
LVDS interface:
Support 18-bit single channel LVDS, resolution up to 1600x1200
CCFL interface:
1 x CCFL for LCD Panel Backlight Inverter
Storage
SATA: 1x Serial ATA ports
U-DOC : By option
CF: 1x Compact Flash Socket
Expansion
1x PCI-104 Slot
Audio
Realtek ALC888 CODEC for High Definition
1x Mic-In / 1x Line out Phone Jack
On board LAN
LAN Chip: Realtek RTL8111C-GR PCI Express Gigabit Ethernet
Support Boot From LAN (PXE)
1x RJ45 connector w/ LED
I/O Interface
Parallel port :1 x Parallel Port 26-pin Box header
Serial port: 4 ports, 1x DB9 port, three 2x5-pin Box headers
USB 2.0 : 6 ports, 2x edge ports and 2 ports by Jst connector
EBC340 User's Manual
SIO2 support RS232/422/485 w/10pin Box header
