Single Board Computer
EBC 580 Series
User's Manual
April-12-2006 Build
Nov-15-2006 Update
Prepared by Zack

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EBC 580 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nexcom EBC 580

Summary of Contents for Nexcom EBC 580

  • Page 1 Single Board Computer EBC 580 Series User’s Manual April-12-2006 Build Nov-15-2006 Update Prepared by Zack...

  • Page 2: Preface

    Any implied warranties of merchantability of fitness for any particular purpose is also disclaimed. Acknowledgements The EBC 580 series is a trademark of NEXCOM international CO., LTD. All other product names mentioned herein are registered trademarks of their respective owners. Regulatory Compliance Statements This section provides the FCC compliance statement for Class A devices and describes how to keep the system CE compliant.

  • Page 3: Ce Certification

    Safety Information Before installing and using the EBC 580, note the following precautions: Read all instructions carefully. Do not place the unit on an unstable surface, cart, or stand.

  • Page 4: Table Of Contents

    2.1 Before You Begin……………………………………………..….……………………………………13 2.2 Precautions………………………………………………………………………………………... …..13 2.3 Setting Jumpers…………………………………………………………………………………… …..13 2.4 Location of Jumpers………………………………………………………………………………. …..15 2.5 Function of Jumper………………………….……………………………………………………..15 Chapter 3 Expansion 3.1 System Memory………………………………………………………………………………….…….26 3.2 Installing DIMM………………………………………………………………………………….. ….. 26 3.3 Installing Compact Flash………………………..…………………………………………………….. 29 EBC 580 User’s Manual Table of Content...
  • Page 5 EBC 580 User’s Manual...

  • Page 6: Chapter 1 General Information

    Chapter 1 General Information EBC 580 User’s Manual Chapter 1...

  • Page 7: Main Feature

    • Compact Flash socket • USB 2.0 Port x 4, COM x 4 • 1.2 Specifications Figure 1.1: Block Diagram of EBC 580 System Architecture - 5.25” Embedded SBC CPU Support - Eden V4 400MHZ or 1GHZ (5W) FANless Possibility EBC 580 User’s Manual...
  • Page 8 - I2C: On board 3 pin header for I2C, one pin for GND - One 32 bit/33MHZ PCI Slot support PCI Expansion. - PCI Expansion Slot position is compatible with EBC 569. And Expansion Slot support NEXCOM PCI Riser Card: EBC 580 User’s Manual Chapter 1...
  • Page 9 BIOS default setting is as shown below: POWER -SUPPLY TYPE [ATX] AUTO PWR-FAILURE RESUME [ON] - AT mode Power Required: +5V/+12V No Power On push Button, No Software Shutdown function and No LAN1 remote wake up EBC 580 User’s Manual Chapter 1...

  • Page 10: Power Consumption Measurement

    EBC-580-715 Power Consumption Power Type +12V +5VSB Mode Power-On 0.81A 2.70A AT Mode 1.30A 2.80A 0.28A ATX Mode EBC-580-E10 Power Consumption Power Type +12V +5VSB Mode Power-On 0.46A 2.71A AT Mode 0.39A 2.59A 0.04A ATX Mode EBC 580 User’s Manual Chapter 1...

  • Page 11: Board Layout

    1.4 Board Layout Figure 1.2: Overview of EBC 580 EBC 580 User’s Manual Chapter 1...

  • Page 12: Board Dimensions

    1.5 Board Dimensions Figure 1.3: Mechanical Drawing of the EBC 580 EBC 580 User’s Manual Chapter 1...
  • Page 13 Chapter 2 Jumper Setting EBC 580 User’s Manual...

  • Page 14: Before You Begin

    ♦ Hold electronic circuit boards (such as the EBC 580 board) by the edges only. Do not touch the components on the board unless it is necessary to do so. Don’t flex or stress the circuit board.

  • Page 15: Setting Jumpers

    OPEN. Open (Off) Short (On) These illustrations show a 3-pin jumper. Pins 1 and 2 are SHORT. Table 2-1: Setting Jumpers EBC 580 User’s Manual...

  • Page 16: Location Of Jumpers

    ◎J1 (USB)：：JST 1x6 2.0mm Male 180-degree connector Pin NO. Description VCC5 USBP3N USBP2N USBP3P USBP2P ◎J3 (CCFL)：：JST 1x7 2.0mm Male 180-degree connector Pin NO. Description Pin NO. Description VDD5SAFE +12V +12V Back light Enable Back light control EBC 580 User’s Manual...
  • Page 17 ◎JP11(IrDA) ：Pin header 1x5 2.54mm Male 180-degree connector Pin NO. Description Pin NO. Description IRTX IRRX ◎JP17(Digital I/O)：Pin header 2x4 2.54mm Male 180-degree connector Pin NO. Description Pin NO. Description Digital Input 1 Digital Output 1 Digital Input 2 Digital Output 2 EBC 580 User’s Manual...
  • Page 18 SMBus Data SMBus Clock ◎JP18(I2CBus) ：Pin header 1x3 2.0mm Male 180-degree connector Pin NO. Description Pin NO. Description SMBus Data SMBus Clock ◎JP20 (Power Select) Pin NO. Description Pin NO. Description AT power supply ATX power supply EBC 580 User’s Manual...
  • Page 19 Auto form feed# DATA0 Error# DATA1 Initialize DATA2 Printer select IN# DATA3 Chassis GND DATA4 Chassis GND DATA5 Chassis GND DATA6 Chassis GND DATA7 Chassis GND Acknowledge# Chassis GND Busy Chassis GND Paper empty Chassis GND Printer select EBC 580 User’s Manual...
  • Page 20 Pin NO. Description Panel Power Panel Power CLK1P CLK1M +12V +12V ◎CN2 (LVDS2) (Slave) Pin NO. Description Pin NO. Description Panel Power DOB0P DOB3P DOBOM DOB3M Panel Power DOB1P DOCLK2P DOB1M DOCLK2M +12V DOB2P +12V DOB2M EBC 580 User’s Manual...
  • Page 21 Data terminal ready B (RS422 RX-) Ring indicator B (RS422 CTX-) Data carrier detect C Data set ready C Receive data C Request to send C Transmit data C Clear to send C Data terminal ready C Ring indicator C EBC 580 User’s Manual...
  • Page 22 DMA Acknowledge# IRQ14 Disk address1 DMA66 Detect Disk address0 Disk address2 HDC CS1 HDC CS3 HD active LED ◎CN6 (PCI) ◎CN8 (SATA1) Pin NO. Description Pin NO. Description ◎CN10 (SATA2) Pin NO. Description Pin NO. Description EBC 580 User’s Manual...

  • Page 23: Gpio Programming Guide

    When set to a ‘1’, the incoming/outgoing port value is inverted. When set to a ‘0’, the incoming/outgoing port value is the same as in the data register. SIO_PORT EQU 2EH SIO_ENTRY EQU 087H SIO_EXIT EQU 0AAH EBC 580 User’s Manual...
  • Page 24 Bit [7：0] = 0x00 Time-out Disable = 0x01 Time-out occurs after 1 second/minute = 0x02 Time-out occurs after 2 second/minutes = 0x03 Time-out occurs after 3 second/minutes ..................= 0xFF Time-out occurs after 255 second/minutes WDT_CRWE EQU 0F5H Logical Device 8 EBC 580 User’s Manual...
  • Page 25 Set timer to be reset upon mouse or keyboard interrupt mov dx,SIO_PORT mov al,WDT_CRWE out dx,al inc dl mov al,10h ;Watch Dog Timer Status, R/W：set "1" out dx,al SIO exit configuration procedure mov dx,SIO_PORT mov al,SIO_EXIT out dx,al EBC 580 User’s Manual...

  • Page 26: Chapter 3 Expansion

    Chapter 3 Expansion EBC 580 User’s Manual...

  • Page 27: System Memory

    3.1 System Memory EBC 580 incorporates VIA CN700chipset supports up to 1GB un-buffered non-ECC DDR 333/400 SDRAM 3.2 Installing DIMM To install DIMM 1. Make sure the two handles of the DIMM sockets are in the “open” position, i.e. the handles stay outward.
  • Page 28 2. Slowly slide the DIMM modules along the plastic guides in the both ends of the socket. Figure 3-2: How to Install DIMM (2) EBC 580 User’s Manual...
  • Page 29 Figure 3-3: How to Install DIMM (3) 4. To take away the memory module, just push the both handles outward, the memory module will be ejected by the mechanism in the socket. Figure 3-4: How to Install DIMM (4) EBC 580 User’s Manual...

  • Page 30: Installing Compact Flash

    3.3 Installing Compact Flash 1. To install a Compact Flash memory card into EBC 580, align the notches on the card with the Compact Flash socket in the EBC 580. Then firmly insert the card into the socket until it is completely seated.
