8 GPIO lines via header (GPI 0~3 and GPO 0~3)
1 x Power LED and 1 x HDD Active LED Pin header
1 x DB15 VGA port
1x Keyboard/Mouse pin header
Onboard Buzzer / SMBus 2.0 /Reset SW
Power Input
Support AT mode only
6-pin power connector for +5V / +12V power in
3-pin Jst connector with PS_ON# directly connected to GND for ATX power supply
(Without power on push button function)
System Management
Monitoring of 4 voltages (Vcore,+12V, +3.3V, +1.5V)
2 Temperatures (CPU, System)
On board RTC
On chip RTC with battery back up / External Li-ion Battery
RTC Torrance less than 2sec (24 hours) under 25˚C
BIOS
Award system BIOS
8M bits SPI ROM
Environment
Operating temperatures: 0° C to 60° C
Storage temperatures:-20˚C to 85˚C
Relative Humidity: Operating 10%~90%, non-condensing
Certifications
CE
FCC Class A
