Nexcom EBC340 User Manual

Hide thumbs Also See for EBC340:
Table of Contents

Advertisement

Quick Links

Download this manual
www.nexcom.com
Single Board Computer
EBC340
User's Manual
Apr.-01-2009 Build
User's Manual is subject to change without prior notice.
For any update, please visit our website: www.nexcom.com
k

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EBC340 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nexcom EBC340

Summary of Contents for Nexcom EBC340

  • Page 1 Single Board Computer EBC340 User’s Manual Apr.-01-2009 Build User’s Manual is subject to change without prior notice. For any update, please visit our website: www.nexcom.com...

  • Page 2: Preface

    This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. No part of this manual maybe reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from NEXCOM International Co., Ltd.

  • Page 3: Ce Certification

    Safety Information Before installing and using the EBC340, note the following precautions:  Read all instructions carefully.  Do not place the unit on an unstable surface, cart, or stand.

  • Page 4: Table Of Contents

    2.5 Function of Jumpers and Connectors…………….………………………………………………..14 GPIO Programming Guide………………………………………………………………………………28 Chapter 3 Expansion 3.1 System Memory…………………………………………………………………………………..…….31 3.2 Installing Compact Flash……………….……...………………………………………..…………….. 32 Chapter 4 BIOS Setting 4.1 Entering Setup………………………………………………………………………………………….34 4.2 Getting Help……………………………………………………………………………………………34 4.3 The Main Menu………………………………………………………………………………………...36 EBC340 User’s Manual Table of Content...

  • Page 5: Chapter 1 General Information

    Chapter 1 General Information EBC340 User’s Manual Chapter 1...

  • Page 6: Specification

    Intel® 82801GBM (ICH7-M) Graphic  Intel® 945GSE integrated graphics  Support Dual Independent Display:CRT+LVDS  CRT: 1 x DB15 VGA CON  LVDS: 1x DF13 20-pin connector Storage  Support 1x Type I/II Compact Flash socket EBC340 User’s Manual Chapter 1...
  • Page 7 On chip RTC with battery back up / External Li-ion Battery  RTC Torrance less than 2sec (24 hours) under 25˚C BIOS  Award system BIOS  8M bits SPI ROM Operating Systems  Windows XP,XP Embedded, CE Certification  EBC340 User’s Manual Chapter 1...

  • Page 8: Power Consumption Measurement

     100% RoHS competed Environment  Operating temperatures: 0°C to 60°C  Storage temperatures:-20˚C to 85˚C  Relative Humidity: Operating 10%~90%, non-condensing 1.2 Power Consumption Measurement EBC340 Power Consumption +12v-to-Vcore +12v-to-1.8v +12v-to-0.9v 5v-to-1.5v 5v-to-1.05v +12v-to-3.3v Power Type +12V DC/DC DC/DC...

  • Page 9: Board Layout

    1.3 Board Layout  Figure 1.2: Overview of EBC 340  1.4 Board Dimensions Figure 1.3: Mechanical Drawing of the EBC 340 EBC340 User’s Manual Chapter 1...
  • Page 10 Chapter 2 Jumper Setting EBC 340 User’s Manual...

  • Page 11: Before You Begin

    This chapter of the User’s Manual describes how to set jumpers. Note: The procedures that follow are generic for all EBC340. 2.1 Before You Begin Ensure you have a stable, clean working environment. Dust and dirt can get into components and cause a malfunction.

  • Page 12: Setting Jumpers

    2.3 Setting Jumpers A jumper is the simplest kind of electric switch. It consists of two metal pins and a cap. When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is SHORT.

  • Page 13: Location Of Jumpers

    2.4 Location of Jumpers Figure 2-1: Jumper Location EBC 340 User’s Manual...

  • Page 14: Function Of Jumpers And Connectors

    2.5 Functions of Jumpers and Connectors ◎ VGA Port VGA1 (D-Sub 15 pins) Pin Definition: VGA1 Pin NO. Description Pin NO. Description RED_VGA VGA_VCC GREEN_VGA BLUE_VGA VGA_DDC_DATA G_HSYNC G_VSYNC VGA_DDC_CLK ◎ LVDS CON CN6 ( 2 X10 2.0 Pitch Pin Definition: CN6 Pin NO.
  • Page 15 ◎ CCFL CON J4 (JST 7 Pins 2.54 Pitch) Pin Definition: J4 Pin NO. Description Pin NO. Description +12V +12V Brightness Ctrl Backlight Enable ◎Panel Power selection: Pin header 1x3 2.54 Pitch. Pin Definition: JP8 Pin NO. Description VCC5 Panel power VCC3 ◎...
  • Page 16 Pin NO. Description RESET# ◎ HDD Active LED: Pin header 1x2 2.0 Pitch. Pin Definition: JP3 Pin NO. Description VCC5 HD_LED# ◎Power LED: Pin header 1x2 2.0 Pitch. Pin Definition: JP4 Pin NO. Description VCC5 ◎ SMBus: Pin header 1x2 2.0 Pitch. Pin Definition: JP5 Pin NO.
  • Page 17 Pin Definition: JP6 Pin NO. Description VCC3 LAN1_ACTLED# ◎ LAN Link LED Pin header 1x2 2.0 Pitch. Pin Definition: JP7 Pin NO. Description VCC3  LAN1_LINKLED# ◎P/S 2 Keyboard / Mouse Pin header 2x4 2.54 Pitch. Pin Definition: JP9 KM1 FOR KEYBOARD/ MOUSE: Pin NO.
  • Page 18 ◎ PCI104 Connector A. Connector size: 4X30 pin B. Connector location: CN1 C. Connector pin definition： Signal Signal VCC5 PCI_AD1 PCI_AD5 PCI_AD4 PCI_CBE#0 PCI_AD8 PCI_AD11 PCI_AD10 PCI_AD14 VCC3 PCI_AD15 PCI_SERR# PA10 PC10 VCC3 PA11 PCI_STOP# PC11 PCI_LOCK# PA12 VCC3 PC12 PA13 PCI_FRAME# PC13...
  • Page 19 PA28 PC28 VCC5 PA29 VCC12 PC29 PCI_IRQ#F PA30 VCC12N PC30 PCI_GNT#5 PCI_AD0 PCI_AD2 VCC5 PCI_AD3 PCI_AD7 PCI_AD6 PCI_AD9 PCI_AD13 PCI_AD12 PCI_CBE#1 VCC3 PCI_PAR PB10 PCI_PERR# PD10 PB11 VCC3 PD11 PB12 PCI_TRDY# PD12 PCI_DEVSEL# PB13 PD13 VCC3 PB14 PCI_AD16 PD14 PCI_CBE#2 PB15 VCC3 PD15...
  • Page 20 AD23 : F G H E EBC 340 User’s Manual...
  • Page 21 ◎ SATAII ports J1 Standard Serial ATAII 1.27mm connector Pin definition： Pin NO. Description Pin NO. Description TXP0 TXN0 RXN0 RXP0 ◎ COM 1 A. Connector size: 2 X 20 = 40 Pin B. Connector location: JP1 Connector pin definition Signal ◎...
  • Page 22 CN4 , CN2 , CN3 Connector pin definition Signal COM2 selection: ◎ SW1. 1-20 2-19 3-18 4-17 5-16 6-15 7-14 8-13 9-12 10-11 RS232 OFF RS422 OFF RS485 EBC 340 User’s Manual...
  • Page 23 ◎ Compact Flash CN10 (Compact Flash TYPE 2) Pin Definition: Pin NO. Description Pin NO. Description SDD3A SDD4A SDD5A SDD6A SDD7A SDCS#1 SDA2A SDA1A SDA0A SDD0A SDD1A SDD2A CF_CD2# CF_CD1# SDD11A SDD12A SDD13A SDD14A SDD15A SDCS#3 SDIOR# SDIOW# HDIRQ14 CF_SEL# IDERST# SIORDY SDREQ...
  • Page 24 SDD10A ◎ USB Port CN7 Dual USB port. Pin Definition: CN7: Pin NO. Description Pin NO. Description P5V_USB_P01 P5V_USB_P01 USB0- USB1- USB0+ USB1+ ◎ Parallel Interface CN5 (2.0mm Box Header) Pin Definition: CN5 Pin NO. Description Pin NO. Description STB# AFD- ERR- INIT-...
  • Page 25 BUSY SLCT ◎GPIO connector 2 x 5 2.0mm Pin header Pin Definition: J5 VCC5 SIO_GPI54 SIO_GPO50 SIO_GPI55 SIO_GPO51 SIO_GPI56 SIO_GPO52 SIO_GPI57 SIO_GPO53 ◎ USB Jst Connector JST 6 Pins 2.0 Pitch Pin Definition: J6 Pin NO. Description P5V_USB_P23 USB2- USB2+ USB3- USB3+ EBC 340 User’s Manual...
  • Page 26 ◎ SYSTEM FAN. FAN (Wafer-2.54mm Male 180) Pin Definition: FAN1 Pin NO. Description SENSE ◎ DC Power input Connector: 1x 6 Pin Power connector: Pin Definition: J2 Pin NO. Description VCC12 VCC5 VCC5 ◎ ATX power connector 1X3 JST 2.5mm Connector Pin Definition: J3 Pin NO.
  • Page 27 PS_ON# ◎USB DOM Connector: Pin Headr 2x5 2.54mm Pitch Pin Definition: J7 Signal Signal P5V_USB_P45 P5V_USB_P45 USB4- USB5- USB4+ USB5+ uDOC_OC# ◎ Line-Out Connector: CN8 Phone Jack Pin NO. LOUT_R LOUT_L ◎ Mic-In Connector: CN9 Phone Jack EBC 340 User’s Manual...
  • Page 28 Pin NO. MIC_R MIC_L ◎ LAN1 connector: A. Connector size: RJ45+LED B. Connector location: CN8 C. Connector pin definition Signal Signal LAN1_TXD0P LAN1_TXD0N LAN1_TXD1P LAN1_TXD2P LAN1_TXD2N LAN1_TXD1N LAN1_TXD3P LAN1_TXD3N LAN1_LINKLED# VCC3 LAN1_ACTLED# VCC3 GND_CHASSIS GND_CHASSIS EBC 340 User’s Manual...

  • Page 29: Gpio Programming Guide

     GPIO Programming Guide: EBC 340 User’s Manual...
  • Page 30 EBC 340 User’s Manual...

  • Page 31: Chapter 3 Expansion

    Chapter 3 Expansion EBC 340 User’s Manual...

  • Page 32: System Memory

    3.1 System Memory EBC 340 incorporates Intel 945GSE Express chipset chipset supports up to 1GB un-buffered non-ECC DDR2 SDRAM. Installing memory 1.To install a memory into socket,insert it to socket notches. 2.Then press the memory down until completely seated within the springs. EBC 340 User’s Manual...

  • Page 33: Installing Compact Flash

    3.2 Installing Compact Flash 1. To install a Compact Flash memory card into EBC 320-JB, align the notches on the card with the Compact Flash socket in the EBC 320-JB. Then firmly insert the card into the socket until it is completely seated.

  • Page 34: Chapter 4 Bios Setting

    Chapter 4 BIOS Setting EBC 340 User’s Manual...

  • Page 35: Entering Setup

    The Chapter shows the currently BIOS setup picture is for reference only, which may change by the BIOS modification in the future. Any Major updated items or re-version, user can download from NEXCOM web site http://www.nexcom.com.tw or any unclear message, can contact NEXCOM Customer Service people for help http://www.nexcom.com.tw/contact/contact.htm  4.1 Entering Setup Power on the computer and press <Del>...
  • Page 36 Status Page Setup Menu/Option Page Setup Menu Press <F1> to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window press <Esc>. EBC 340 User’s Manual...

  • Page 37: The Main Menu

     4.3 The Main Menu Once you enter Award BIOS CMOS Setup Utility, the Main Menu (Figure 1) will appear on the screen. The Main Menu allows you to select from ten setup functions and two exit choices. Use arrow keys to select among the items and press <Enter>...
  • Page 38 Use this menu to specify your settings for power management PNP/PCI Configuration This entry appears if your system supports PnP / PCI. PC health Status Display CPU/System Temperature, Fan speed. Load Optimized Defaults Use this menu to load the BIOS default values that are factory settings for optimal Uperformance system operations.
