HINGING THE ELEVATOR.

Glue the rudder hinges in place using the
same techniques used to hinge the ailerons.

HINGING THE RUDDER.

Glue the rudder hinges in place using the
same techniques used to hinge the ailerons.
Hinge.
INSTALL THE AILERONS CONTROL
HORN.
1) Locate the hardware necessary to install
the control horns for the ailerons.
Fiberglass control horn
2)Position the Control horn on the Aileron
and use 30-minute Epoxy
Aileron control horn.
www.seagullmodels.com
same method as same as the aileron control
horns.
Position the Control horn on the Aileron and
use 30-minute Epoxy
INSTALL RUDDER CONTROL HORN.
Repeat steps to install the rudder control horn
as same as steps done for ailerons.
.
Epoxy.
INSTALL ELEVATOR CONTROL HORN.
Install the elevator control horn using the
Fiberglass control horn
Epoxy.
Elevator control horn.
Fiberglass control horn
Rudder control horn.
.
.
Epoxy.
5
