Installing The Optional Internal Dual Sd Module; Heat Sink And Processor - Dell poweredge t330 Owner's Manual

Convention
D
E
Next steps
1. Install the internal dual SD module.
2. Follow the procedure listed in
Related Tasks
Removing an optional internal SD card

Installing the optional internal dual SD module

Installing the optional internal dual SD module
Prerequisites
CAUTION: Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
directed by the online or telephone service and support team. Damage due to servicing that is
not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that came with the product.
1. Ensure that you follow the
2. Follow the procedure listed in
Steps
1. Locate the Internal Dual SD Module (IDSDM) connector on the system board.
2. Align the IDSDM with the IDSDM connector on the system board.
3. Push the IDSDM until it is firmly seated on the system board.
Next steps
1. Install the SD card(s).
NOTE: Temporarily label each SD card with its corresponding slot before removal. Replace the
SD card(s) into the same slots.
2. Follow the procedure listed in
Related Tasks
Installing an optional internal SD card

Heat sink and processor

100
IDSDM indicator code
Amber
Not lit
After working inside your
Safety instructions.
Before working inside your
After working inside your
Condition
Indicates that the card is offline, has failed, or is
write-protected
Indicates that the card is missing or is booting
system.
system.
system.
